EXPLOSION PROOF
The ANTI EXPLOSION range is specially designed to be used in potentially explosive environments, and they are declared Category II according to the ATEX 2014/34/UE. It has standard, autotest and DALI versions. Its high protection rates (IP67 and IK06) makes it possible for the fitting to be installed in places declared category II according to ATEX 2014/34/UE/Zone 1,21 Exd. ICC T6.
Technical characteristics
| Installation | Explosion Proof |
| Color | Glass |
| Light source | Fluorescent |
| Autonomy | 1h |
| Light range | 200 - 400 |
| Dali option |
|
| Waterproof |
|
| Operating mode | Non Maintained |
| Version | Standard | Self-test | DALI |
Downloads
References
Use the filters to see the model reference of this product that best fits your project:
| Reference | Finish | Version | Lumens | Temperature | Autonomy | Battery | Operating mode | Technical datasheet | LDT Curve | Certificates |
|---|---|---|---|---|---|---|---|---|---|---|
| EX-200 | Glass | Standard | 200 | 4000 | 1 | Ni-Cd | Non Maintained |
|
|
|
| EX-400 | Glass | Standard | 400 | 4000 | 1 | Ni-Cd | Non Maintained |
|
|
|
| EXA-200 | Glass | Self-test | 200 | 4000 | 1 | Ni-Cd | Non Maintained |
|
|
|
| EXA-400 | Glass | Self-test | 400 | 4000 | 1 | Ni-Cd | Non Maintained |
|
|
|
| EXID-200 | Glass | DALI | 200 | 4000 | 1 | Ni-Cd | Non Maintained |
|
|
|
| EXID-400 | Glass | DALI | 400 | 4000 | 1 | Ni-Cd | Non Maintained |
|
|
|
